Tipo | Tamaño máximo de alimentación (mm) | Capacidad de producción (toneladas/hora) | Potencia (kW) | Peso (toneladas) | Dimensiones (mm) |
---|---|---|---|---|---|
PFW1214Ⅲ | 250 | 90-170 | 132(175) | 16 | 2550 × 2310 × 2100 |
PFW1214Ⅱ | 500 | 130-200 | 132(175) | 18.5 | 2400 × 2310 × 2550 |
PFW1315Ⅲ | 300 | 180-270 | 200(270) | 20 | 2960 × 2570 × 2380 |
PFW1315Ⅱ | 600 | 180-320 | 200(270) | 21.5 | 2700 × 2570 × 2800 |
PFW1318Ⅲ | 300 | 220-300 | 250(350) | 23 | 2960 × 2870 × 2380 |
PFW1318Ⅱ | 700 | 240-400 | 250(350) | 25.5 | 2700 × 2870 × 2800 |
PFW1415Ⅲ | 350 | 280-350 | 250(350) | 22.5 | 3120×2650×2660 |
PFW1415Ⅱ | 700 | 300-480 | 250(350) | XXV | 2900 × 2700 × 3000 |
NOTE: The above capacity figures are based on the general throughput of medium hardness materials. Depending on different feeding, size, rock types and water content, the actual performance may be different.
